Technical data
Glass type -EI 30 insulated fire resistant glass
Glass thickness- 15mm.(5mm tempered glass+ invisible intumescent layer+5mm tempered glass)
- 33mm.(5mm low-E glass+13mm air+5mm tempered glass+ invisible intumescent layer+5mm tempered glass)
Frame- Aluminium alloy with Thermal brake (56mm-85mm frames) with intumescent filling.
Performance data-
Weight- 33kg/m2
Light transmission-84%
U value- 4.2 for 15mm, and 1.9 for 33mm
SHGC -0.58 for 15mm or 0.49 for 33mm
Deflection test- Positive- 1200Pa
- Negative -1200Pa
Air infiltration test- Low
Water penetration test- 300Pa
Ultimate strength test- Positive -3000Pa
- Negative -3000-Pa
Dimensions and weight- Weight for SQM 38kg for 56mm frame or 50kgs for 85mm frame.
Colour options-
Standard colour options-15 colour variations as standard and Powder coat custom colours can be added at an extra cost.
